C10100 Oxygen-Free Electronic Copper
C10100, also known as Oxygen-Free Electronic Copper (OFE), is a high-purity copper grade with a minimum copper content of 99.99% and very low oxygen content (typically ≤ 0.0005%). This grade is widely used in electrical, electronic, and vacuum applications due to its excellent electrical conductivity, thermal conductivity, corrosion resistance, and ductility.
C10100 Copper Chemical Composition
The typical chemical composition of C10100 (UNS C10100, ASTM B170) is as follows:
Element | Content (%) |
Copper (Cu) | ≥ 99.99 |
Oxygen (O) | ≤ 0.0005 |
Silver (Ag) | ≤ 0.002 |
Other Elements | ≤ 0.005 |
C10100 Copper Mechanical Properties
C10100 shows stable mechanical properties under annealed and hard temper conditions:
Temper | Tensile Strength Rm (MPa) | Yield Strength Minimum Rp0.2 (MPa) | Elongation Minimum A50mm (%) | Hardness HV | Bending 90° gw (rel. Bending Radius R/T) | bw Strip Thickness ≤ 0.50mm |
R220 | 220–260 | ≤ 140 * | 33 | 40–65 | 0 | 0 |
R240 | 240–300 | 180 | 8 | 65–95 | 0 | 0 |
R290 | 290–360 | 250 | 4 | 90–110 | 0 | 0 |
R360 | ≥ 360 | 320 | 2 | ≥ 110 | 0 | 0.5 |
C10100 Copper Manufacturing & Heat Treatment Process
C10100 oxygen-free copper can be produced by casting, hot rolling, forging, and extrusion. For critical applications, forging ensures fine grain structure, excellent conductivity, and dimensional stability.
- Forging Temperature Range: 760–870 °C
- Annealing Temperature Range: 400–600 °C
- Heat Treatment: Typically supplied in annealed condition to maximize ductility and conductivity.
